Diskoteksanlæg JPS Music DJ Udstyr 200000
2.245 visninger
|
Oprettet:
Diskoteksanlæg JPS Music DJ Udstyr
Prisklasse:
200000
Forstærker/reciever:
FORSTÆRKER - SKAB:
______________________________________
Professional flight case for 483 mm units (19")
castors
Strength: 9 mm
Outside dimensions (WxDxH): 550 x 800 x 1060 mm
Interior dimensions:
Mounting width: 510 mm (19")
Mounting height: 900 mm (20 U)
Mounting depth: 550 mm (90 mm per cover)
Corner dimensions: 56 mm
Weight: 37.5 kg
______________________________________
FORSTÆRKER 1
B-52 US-1800 Prof. forstærker 2 x 475 W i 4 ohm
Højde 2 rackunits
Indgange 2 x XLR/Jack
Udgange
2 x Speakon 5 pol
2 x skrueterminal
Vidrekobling 2 x XLR
Frekvensområde 5Hz - 60kHz
Forvrængning < 0.03%
Signal to Noise Ratio Bedre end 100 dB
Inputsensitivity 1.23 Vrms (+4 dBu)
Input Impedance 30K ohms Balanceret
Watt ved 8 ohm 2 x 300 W
Watt ved 4 ohm 2 x 475 W
Watt ved 2 ohm 2 x 700 W
Brokoblet 8 ohm 950 W
Brokoblet 4 ohm 1400 W
Køling Regulerende blæsere
Vægt 16 kg
______________________________________
FORSTÆRKER 2
B-52 US-3000 Prof. forstærker 2 x 800 W i 4 ohm
Højde 2 rackunits
Indgange 2 x XLR/Jack
Udgange
2 x Speakon 5 pol
2 x skrueterminal
Vidrekobling 2 x XLR
Frekvensområde 5Hz - 60kHz
Forvrængning < 0.03%
Signal to Noise Ratio Bedre end 100 dB
Inputsensitivity 1.23 Vrms (+4 dBu)
Input Impedance 30K ohms Balanceret
Watt ved 8 ohm 2 x 500 W
Watt ved 4 ohm 2 x 800 W
Watt ved 2 ohm 2 x 1200 W
Brokoblet 8 ohm 1600 W
Brokoblet 4 ohm 2400 W
Køling Regulerende blæsere
Vægt 19 kg
______________________________________
FORSTÆRKER 3
OMNITRONIC P-2000 forstærker,2x1000W/4Ohm
Power supply: 115/230 V AC, 50/60 Hz ~
Power-range: 230 V ± 10 % (206 V - 253 V)
Power consumption (max.): 3500 W
Power output sine:
Stereo 4 Ohm 2 x 1000 W
Stereo 8 Ohm 2 x 625 W
8 Ohms bridged 1 x 1875 W
Frequency range: 40 - 40 000 Hz, ± 3 dB
Damping-factor: > 400
Distortion factor: 0.01 %
Signal to Noise Ratio: 90 dB
Channel seperation (at 1 KHz): 70 dB
Min. input sensitivity: 0.77 V/26 dB/1.4 V
Input impedance: 20 kOhms (balanced)
Slew-rate: 60 V/æsec
Input-connectors: 2 x XLR-female-plug, 2 x 1/4"-jack-plug
Output-connectors: 2 x Speaker (stereo), 1 x Speaker (bridge), 2 x Banana/screw combination
Control elements: Power switch, input attenuators (one per channel), Mode switch - Stereo/Parallel/Bridged, Ground Lift, Input-Level-Select (0.77 V/26 dB/1.44 V), limiter
LED indicators (per channel): Power, Protect, Signal, Mode
Protection circuits: Short-circuit, DC-protection-circuit, Thermal protection-circuit, Softstart
Construction: Steel chassis, aluminium frontpanel
Dimensions: 490 x 482 x 100 mm
Minimum mounting depth: 480 mm
Weight: 29 kg
Power/weight-relation: 69 W/kg
______________________________________
FORSTÆRKER 4
OMNITRONIC P-2000 forstærker,2x1000W/4Ohm
Power supply: 115/230 V AC, 50/60 Hz ~
Power-range: 230 V ± 10 % (206 V - 253 V)
Power consumption (max.): 3500 W
Power output sine:
Stereo 4 Ohm 2 x 1000 W
Stereo 8 Ohm 2 x 625 W
8 Ohms bridged 1 x 1875 W
Frequency range: 40 - 40 000 Hz, ± 3 dB
Damping-factor: > 400
Distortion factor: 0.01 %
Signal to Noise Ratio: 90 dB
Channel seperation (at 1 KHz): 70 dB
Min. input sensitivity: 0.77 V/26 dB/1.4 V
Input impedance: 20 kOhms (balanced)
Slew-rate: 60 V/æsec
Input-connectors: 2 x XLR-female-plug, 2 x 1/4"-jack-plug
Output-connectors: 2 x Speaker (stereo), 1 x Speaker (bridge), 2 x Banana/screw combination
Control elements: Power switch, input attenuators (one per channel), Mode switch - Stereo/Parallel/Bridged, Ground Lift, Input-Level-Select (0.77 V/26 dB/1.44 V), limiter
LED indicators (per channel): Power, Protect, Signal, Mode
Protection circuits: Short-circuit, DC-protection-circuit, Thermal protection-circuit, Softstart
Construction: Steel chassis, aluminium frontpanel
Dimensions: 490 x 482 x 100 mm
Minimum mounting depth: 480 mm
Weight: 29 kg
Power/weight-relation: 69 W/kg
______________________________________
DELEFILTRE:
OMNITRONIC DXO-24 Digital crossover
Power supply: 90-250 V AC, 50/60 Hz ~
Power consumption: 30 W
Inputs: 2 x XLR, active, balanced with automatic correction for unbalanced loading
Gain range: ± 15 dB
Input impedance: 10 kohms
Frequency Response: 15 Hz - 20 kHz, ± 0,25 dB
15 Hz - 40 kHz, ± 3 dB
Outputs: 4 x XLR, active, balanced
Output impedance: <50 mohms (electronically balanced)
Output gain range: ± 21 dB
Maximum output level: +20 dBu
Frequency Response: 15 Hz - 20 kHz, ± 0,25 dB
15 Hz - 40 kHz, ± 3 dB
Distorsion: 0,005 %, 20 Hz - 20 kHz
S/N ratio: 112 dB (22 Hz - 22 kHz)
Channel separation: 80 dB (30 Hz - 20 kHz)
Filter:
Slopes: 6, 12, 18, 24 or 48 dB/octave
Type: Bessel, Butterworth or Linkwitz-Riley
Crossover frequency: 15 Hz - 20 kHz
Delay: 0~7 ms
Dimensions (WxHxD): 482 x 44 x 223 mm
Weight: 3.6 kg
______________________________________
EQUALIZER: :
OMNITRONIC GEQ-215 Equalizer 2x15-band
Power supply: 230 V AC, 50 Hz ~
Power consumption: 10 W
Input impedance: 10/20 kohms (unb./bal.)
Output impedance: 300/150 kohms (unb./bal.)
In/Out connectors: XLR, jack
S/N ratio: >95 dB
Crosstalk: >90 dB
Distortion: <0.01 %
Frequency range: 20 Hz - 20 kHz, ±0.5 dB
Output level: - ~ to +6 dB
Control range: ±6 dB or ±15 dB
Frequencies: 2x 25/40/63/100/160/250/400/630 Hz, 1/1.6/2.5/4/6.3/10/16 kHz
Low Cut: 30 Hz, -3 dB
Dimensions (WxDxH): 483 x 175 x 44 mm
Weight: 3 kg
______________________________________
MAXIMIZER:
OMNITRONIC AM-21 Sonic maximizer
Power supply: 230 V AC, 50 Hz ~
Power consumption: 10 W
S/N ratio: >90 dB
Frequency range: 20 Hz - 20 kHz
THD: 0.05%
Crosstalk: >80 dB, -3 dB
Bass definition: 0 to +9 dB
Input impedance: 10/20 kohms (unbal./bal.)
Output impedance: 300/150 ohms (unbal./bal.)
Audio connectors: 6.3 mm jack (unbal.), 3-pin XLR (bal.)
Dimensions (WxDxH): 483 x 120 x 46 mm
Weight: 2 kg
______________________________________
